feature

1.1

Model

IN25

1.2

Dynamic Form

electric

1.3

Operation Type

Riding type

1.4

Load

Q

kg

2500

1.5

Center of load distance

C

mm

500

1.6

Wheelbase

X

mm

390

1.7

Wheel distance

y

mm

1665

weight

2.1

Weight (including battery)

kg

3200±100

Tires, chassis

3.1

 Tire type

Solid tire

3.2

Drive wheel size

mm

650-10

3.3

Steering wheel size

mm

18x7-8

3.4

 Wheel QTY(x= drive wheel)

mm

2X/2

3.5

 Wheelbase of driving

b10

mm

960

3.6

 Wheelbase of  steering

b11

mm

950

size

4.1

 The tilt angles of the gantry and the forks, both forward and backward

α/ β (°)

6/10

4.2

 Height of the boom afer down

h1

mm

2180

4.3

 Max lifting height of the standard boom

h3

mm

3000

4.4

Max boom height at lifting

h4

mm

3982

4.5

Hood height

h6

mm

2180

4.6

Seat height

h7

mm

1150

4.7

 Traction pin center height

h10

mm

550

4.8

 Vehicle length

l1

mm

3595

4.9

 Length of the vertical plane of the delivery fork

l2

mm

2485

4.10

Overall width

b1/ b2

mm

1120

4.11

 Fork size

s/ e/ l

mm

40X120X1070

4.12

 External width of fork

b3

mm

1040

4.13

The clearance between the bottom of the fully loaded gantry with ground

m1

mm

175

4.14

 Mini ground clearance of machine body

m2

mm

120

4.15

 The tray 1200*1000 need aisle width

Ast

mm

3900

4.16

 The tray 800*1200 need aisle width

Ast

mm

4100

4.17

 Turning Radius

Wa

mm

2320

Performance parameters

5.1

 Walking speed, full load / empty load

km/ h

11/12

5.2

 Lifting speed, full load / empty load

m/ s

0.26/0.32

5.3

 Downing speed, full load / empty load

m/ s

0.38/ 0.36

5.4

 Max climbing gradient, full load / empty load

%

15

5.5

 Type of vehicle brake

Hydraulic + Mechanical

5.6

Type of packing brake

mechanical

Electric motor, power source

6.1

 Drive motor rated power S2 60minutes

kW

7.5

6.2

 Hoisting motor rated power S3 15%

kW

8

6.3

 Battery voltage / Normal capacity K5

Ah

6.4

 Drive cotrol type

comminicate

*Specifications and configurations are subject to change without prior notice. The images shown may include non-standard configurations.
